Lynx Q 16W GR8 827

Lynx Q

Product Image for 0024944
Lynx Q

More Information

Lamp Safety

Product overview

Product overview
Dimming method 1-10V (Analogue), DALI, Switch-dim (mains-rated)
Product name Lynx Q 16W GR8 827
Technology Compact Fluorescent
Watt (Rated) (W) 16
Lamp shape Other
Type Lynx Q
Cap/Base GR8
Lamp finish Frosted/Coated
General application Education, Hospitality, Logistics & Industry, Museums & Galleries, Office, Retail, Residential & Consumer
ETIM Class EC000087
E-number FI 4940100
E-number SE 8357338
E-number Norway 3845314
Luminous flux (lm) 1050
Colour temperature (K) 2700
Light colour Homelight
CRI (Ra) 82
Colour Variation Initial (SDCM) SDCM5
Photobiological Risk Group Not applicable
Wattage (W) 16
Product Voltage (V) 103
Dimmable No
Average life (Nominal) (h) 10000
Product EAN number 5410288249445

Product Data

General data
Product name Lynx Q 16W GR8 827
Technology Compact Fluorescent
Watt (Rated) (W) 16
Lamp shape Other
Type Lynx Q
Cap/Base GR8
Lamp finish Frosted/Coated
General application Education, Hospitality, Logistics & Industry, Museums & Galleries, Office, Retail, Residential & Consumer
ETIM Class EC000087
E-number FI 4940100
E-number SE 8357338
E-number Norway 3845314
Optical data
Luminous flux (lm) 1050
Luminous flux (Rated) (lm) 1050
Ambient temperature for maximum luminous flux (°C) 25
Colour temperature (K) 2700
Light colour Homelight
Colour Code 827
CRI (Ra) 82
Colour Variation Initial (SDCM) SDCM5
Adjustable chromaticity N
Photobiological Risk Group Not applicable
Rated lumen maint. factor (%) at 4000 h 50Hz 78
Rated lumen maint. factor (%) at 6000 h 50Hz 76
Rated lumen maint. factor (%) at 8000 h 50Hz 75
Electrical data
Wattage (W) 16
Starting time (max) (s) <10s
Warm-up time to 60% of full light (max) (s) 60
Current (A) 0.18
Product Voltage (V) 103
Ignition voltage (V) 450
Control gear required Yes
Transformer required No
Dimmable No
Lamp Energy Label (class) G
kWh per 1000 hours burning time 20
Lifetime data
Average life (Nominal) (h) 10000
Average life (Rated) (h) 10000
Rated survival factor (%) at 2000 h 50Hz 98
Rated survival factor (%) at 4000 h 50Hz 90
Rated survival factor (%) at 6000 h 50Hz 75
Rated survival factor (%) at 8000 h 50Hz 50
Physical data
Nominal Product Length (mm) 136
Nominal Product Width (mm) 133
Nominal Product Height (mm) 26
Max. Length base to base (mm) - A 26
Max. Lamp Length (mm) - C/L 138
Max. Lamp Diameter (mm) - D 13.7
Weight (kg) 0.065
Packaging
Single packaging type Carton
Product EAN number 5410288249445
Packaging single length / height (cm) 14.1
Packaging single width (cm) 2.4
Packaging single depth (cm) 13.7
DUN14 (outer) 15410288249442
Units per outer package 10
Packaging outer length / height (cm) 27.8
Packaging outer width (cm) 17.1
Packaging outer depth (cm) 15.7
Safety data
Lamp mercury content (mg) 4.50
Breakage cleaning instructions Applicable
Recommendation for disposal at end of life Applicable
Special purpose lamp No
Dry applications use only No
Suitable for household illumination Yes
Suitable for accent lighting N/A
